ASTM A179 G-Type Embedded Fin Tube Aluminium 1010 for Gas-to-Gas and Gas-to-Liquid

Dettagli:

Luogo di origine:	Cina
Marca:	YUHONG
Certificazione:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Numero di modello:	Metropolitana di aletta G tipa di ASTM A179

Termini di pagamento e spedizione:

Quantità di ordine minimo:	500 kg
Prezzo:	Negoziabile
Imballaggi particolari:	Cassa in legno piatto/cassa in ferro/confezione con tappo in plastica
Tempi di consegna:	Dipende dalla quantità
Termini di pagamento:	L/C a vista, T/T
Capacità di alimentazione:	10000 pezzi al mese

Contatto

Tutti i prodotti

Tubo senza cuciture in acciaio inossidabile (277)

Tubo senza saldatura di acciaio inossidabile (269)

Tubo di acciaio inossidabile del duplex (128)

Metropolitana di acciaio inossidabile del duplex (27)

Tubo ad ago (86)

Tubo di pinna (596)

scambiatori di calore (10)

tubo dello scambiatore di calore (419)

Fusoli di tubi per scambiatori di calore (37)

Piastra tubiera dello scambiatore di calore (117)

deflettore dello scambiatore di calore (35)

Aria di raffreddamento (7)

Contenitore a pressione (2)

tubo saldato di acciaio inossidabile (57)

Metropolitana saldata dell'acciaio inossidabile (113)

Tubo della lega di nichel (258)

Metropolitana della lega di nichel (75)

Metropolitana della lega di rame (210)

Metropolitana dell'acciaio legato (173)

Metropolitana di titanio (9)

tubo temprato luminoso (153)

Metropolitana di caldaia (138)

montaggio d'acciaio (784)

Flangia d'acciaio (574)

Altri (384)

Descrizione di prodotto dettagliata

Nome del prodotto:	Tubo di pinna	Materiale del tubo:	ASTM A179/ASME SA179
Materiale delle pinne:	Alumini 1010	Tipo di pinna:	Tipo G
Sopravendita di tubo.:	16-63 mm	Lunghezza del tubo:	Personalizzato
Spessore delle pinne:	~0.4mm	Altezza delle pinne:	17 mm al massimo.
Evidenziare:	G-Type Embedded Fin Tube , Aluminium 1010 Fin Tube , ASTM A179 Fin Tube

Embedded Fin Tube ASTM A179 G-Type Fin Tube Fin Aluminium 1010 for Gas-to-Gas and Gas-to-Liquid

ASTM A179 G-Type aluminum 1010 finned tube is a high-efficiency heat exchange element. Its base tube is made of ASTM A179 standard seamless cold-drawn low-carbon steel tube (carbon content ≤0.06%, density about 7.85 g/cm³), which is designed for low to medium temperature (usually below 400°C) heat exchange environment and is suitable for boilers, condensers and other equipment.

The outer surface of the tube is composited with aluminum 1010 spiral fins (purity ≥99.9%, density 2.70 g/cm³) through high-frequency welding or hydraulic expansion process. The high thermal conductivity of aluminum (237 W/m·K) and the expanded surface area of the fins are used to significantly improve the heat transfer efficiency. It is commonly used in air coolers and waste heat recovery systems in petrochemical, power plants and other fields.

Its lightweight structure (difference in density between steel and aluminum) takes into account both strength and heat dissipation requirements, but attention should be paid to the thermal stress that may be caused by the difference in thermal expansion coefficient of steel and aluminum (steel 12×10⁻⁶/°C, aluminum 23×10⁻⁶/°C), as well as the risk of galvanic corrosion of steel and aluminum in humid environments. It is usually necessary to use a galvanized layer or insulating gasket for protection to ensure long-term stable operation.

Chemical Components (%) of ASTM A179 Fin Tubes

C	Si	Mn	P	S	Mo	Cr	V
0.06-0.18	/	0.27-0.63	≤0.035	≤0.035	/	/	/

Mechanical Properties of ASTM A179 Fin Tubes

Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation (%)	Hardness (HRB)
≥325	≥180	≥35	≤72

Application

Power and energy industry: used in thermal power plant condensers and boiler waste heat recovery systems, aluminum fins quickly dissipate the heat of high-temperature flue gas or steam to improve energy efficiency.

Petrochemical: Cooling high-temperature oil and gas or reaction products in air coolers in refineries and chemical plants, corrosion-resistant aluminum fins adapt to corrosive media environments such as sulfur.

Industrial refrigeration: As heat exchange tubes for refrigeration equipment or air-conditioning systems, compact heat exchange is achieved by using the pressure-bearing capacity of steel-based pipes and the high thermal conductivity of aluminum fins.

New energy field: used in solar thermal systems or geothermal stations to transfer and store heat energy, and the lightweight characteristics of aluminum reduce installation complexity.

Shipbuilding and marine engineering: The condensation section of the seawater desalination device protects the steel-aluminum interface through anti-salt spray coating to avoid galvanic corrosion in the marine environment.
