ASTM B407 Incoloy 800H Nickel Alloy Seamless Pipe for High-temperature Service with Creep and Rupture Resistance

Dettagli:

Luogo di origine:	Cina
Marca:	YUHONG
Certificazione:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Numero di modello:	INCOLOY800, INCOLOY 800H, INCOLOY 800HT, INCOLOY 825

Termini di pagamento e spedizione:

Quantità di ordine minimo:	100KG
Prezzo:	Negoziabile
Imballaggi particolari:	pacco Piega-di legno del caso di /Iron di caso con la capsula di plastica/cassa tessuta
Tempi di consegna:	Dipende dalla quantità
Termini di pagamento:	T/T, L/C
Capacità di alimentazione:	1000 tonnellate al mese

Contatto

Tutti i prodotti

Tubo senza cuciture in acciaio inossidabile (308)

Tubo senza saldatura di acciaio inossidabile (297)

Tubo di acciaio inossidabile del duplex (132)

Metropolitana di acciaio inossidabile del duplex (33)

Tubo ad ago (134)

Tubo di pinna (672)

scambiatori di calore (20)

tubo dello scambiatore di calore (443)

Fusoli di tubi per scambiatori di calore (40)

Piastra tubiera dello scambiatore di calore (117)

deflettore dello scambiatore di calore (37)

Aria di raffreddamento (9)

Contenitore a pressione (4)

tubo saldato di acciaio inossidabile (58)

Metropolitana saldata dell'acciaio inossidabile (120)

Tubo della lega di nichel (266)

Metropolitana della lega di nichel (92)

Metropolitana della lega di rame (240)

Metropolitana dell'acciaio legato (204)

Metropolitana di titanio (15)

tubo temprato luminoso (155)

Metropolitana di caldaia (151)

montaggio d'acciaio (826)

Flangia d'acciaio (615)

Altri (401)

Parti di rivestimento (7)

Descrizione di prodotto dettagliata

Evidenziare:

High-temperature Service Nickel Alloy Seamless Pipe

ASTM B407 Standard Incoloy 800H Pipe

Creep and Rupture Resistance UNS N08810 Pipe

ASTM B407 Incoloy 800H (UNS N08810) Nickel Alloy Seamless Pipe

This high-performance seamless pipe is manufactured from Incoloy 800H (UNS N08810) nickel-iron-chromium alloy, fully compliant with ASTM B407 standards. Engineered specifically for demanding high-temperature applications above 593°C (1100°F), it delivers superior resistance to creep, rupture, oxidation, and corrosion.

Product Specifications & Standards

ASTM B407 covers cold-worked and hot-finished annealed seamless pipe and tube requirements, ensuring strict adherence to chemical composition, mechanical properties, heat treatment, and non-destructive testing standards. The controlled grain size and annealed condition optimize performance in extreme temperature environments.

Chemical Composition

Incoloy 800H features a precisely balanced austenitic composition that provides exceptional high-temperature strength and corrosion resistance:

Element	Composition (% by weight)	Role/Effect
Nickel (Ni)	30.0 - 35.0	Base element; provides high-temperature strength, ductility, and resistance to reducing atmospheres
Chromium (Cr)	19.0 - 23.0	Imparts oxidation and corrosion resistance by forming protective Cr₂O₃ scale
Iron (Fe)	Balance (approx. 39.5% min)	Balances cost and contributes to alloy strength
Carbon (C)	0.05 - 0.10	Carefully controlled to enhance high-temperature creep strength
Aluminum (Al)	0.15 - 0.60	Improves high-temperature oxidation resistance and strengthens the alloy
Titanium (Ti)	0.15 - 0.60	Works with Al to form strengthening phases and stabilize structure
Manganese (Mn)	≤ 1.50	Aids in deoxidation during manufacturing
Silicon (Si)	≤ 1.00	Improves oxidation resistance
Copper (Cu)	≤ 0.75	-
Sulfur (S)	≤ 0.015	Controlled impurity to maintain weldability and hot workability

Mechanical & Physical Properties

Delivered in annealed condition with the following minimum room-temperature properties:

Property	Minimum Value	Condition / Notes
Tensile Strength	450 MPa (65,000 psi)	For hot-finished annealed or cold-worked annealed material
Yield Strength (0.2% Offset)	170 MPa (25,000 psi)	-
Elongation	30%	-
Density	8.0 g/cm³	-
Melting Range	1350 - 1400 °C	-

High-Temperature Performance: Excellent long-term strength at elevated temperatures with superior oxidation resistance up to 1100°C. Maintains stability in carburizing and sulfidizing atmospheres common in industrial furnace environments.

Industrial Applications

Petrochemical & Chemical Processing: Ethylene cracking furnace tubes, reformer components, and heat exchangers in corrosive environments up to 1100°C
Heat Treatment Industry: Radiant tubes, muffles, retorts, and furnace fixtures requiring long-term thermal stability
Power Generation & Energy: Advanced nuclear reactor components, steam generators, and waste incineration plant parts
Industrial Heating: Steam superheater tubes, heater element sheaths, and high-temperature fluid transfer lines
